PRESIDON-ML SERIES
MAI

Brand:MAI

Other Data:

Benefits

The ML-MAI is a semi-automatic hot mounting press, meticulously designed for sample preparation. It features easy operation and a thread-locking cover design for added convenience and stability. The machine incorporates a reliable hydraulic system, a button-operated manual pressuring, and an electric heating system, guaranteeing consistent melting of the mounting powder and comprehensive edge protection for the samples. It also supports the following sample preparation processes.



The ML-MAI has a wide range of applications and provides excellent support for sample preparation, material analysis, hardness testing, and other laboratory and production line experiments. Its high stability and user-friendly design enables users to perform sample preparation tasks with ease while ensuring high-quality sample preparation results.

Specification

※Mobiles and tablets can be slid left and right.

Features

Easy Operation

The machine operates in semi-automatic mode, automatically heating to the preset temperature. Users only need to manually add pressure and open the cooling water valve, making it easy to use.



Circulating Cooling Water

The built-in submerged pump socket allows for the external connection of a submerged pump, enabling operation in a circulating cooling mode. This significantly reduces water wastage, aligning with the goals of energy conservation and environmental protection.



Bracket for Handle Assembly

The handle assembly can be placed on the bracket, which is attached to the machine body, effectively increasing space utilization while keeping the workspace neat and eliminating concerns about the handle assembly falling and getting damaged.





Thread-Locking Cover

The top cover adopts a thread-locking design, capable of withstanding greater force and pressure, enhancing its durability and resistance to deformation.





Button-Operated Manual Pressuring

The intuitive button-operated manual pressuring design increases the flexibility of sample preparation, allowing adjustments according to different samples and requirements to achieve better preparation results.





Electric heating device and hydraulic design

An electric heating device increases the temperature quickly and stably, while a hydraulic pressure compensation design ensures stability as well.



Lower Ram with Chamfering Design

A chamfering design can avoid the waste or the damage of SiC paper or polishing cloth during the grinding and polishing process.





Spacer (option)

With an additional spacer, the user can mount two specimens at the same time, greatly reducing the sample preparation time.





Specification



 Model

MA

 Sample Size (mm)

Ø25

Ø25.4

Ø30

Ø31.75

Ø32

Ø38.1

Ø40

Ø50

 Sample Quantity

1~2pcs/per time (Opt for a spacer for 2 pcs)

 Spacer (Option)

Ø25 (ML25H0219A)

Ø25.4 (ML25.4H0219A)

Ø30 (ML30H0219A)

Ø31.75 (ML31.75H0219A)

Ø32 (ML32H0219A)

Ø38.1(ML38.1H0219A)

Ø40 (ML40H0219A)

Ø50 (ML50H0219A)

 Noise Level (dB)

62~73

63~75

 Temperature (°C)

0~250 (Special temperature requirements can be customized)

 Heating Power (W)

1600

2400

 Total Power (W)

2220

3020

 Pressure (kg/cm2)

Manual pressuring 80~600 (1137~8534 psi/ 78~588 bar)

(The actual pressure will be affected by the size of the mounting tube and the material of the powder.)

 Heating Time (s)

99 min 59 sec

 Cooling Time (s)

Manual cooling after heating

 Machine Dimension

500x600x640 WxDxH (mm)

 Machine Weight (kg)

70

71

 Inlet and Outlet Pipe

10mm low pressure pipe (Inlet Ø10Outlet Ø15)

 Cooling Device

Connect to submerged pump for manual cooling

 Power Supply (V)

AC 220 1Ø

 Accessories

Sample Clip 1pc, Funnel 1pc, Spoon 1pc, Mounting Powder 1kg (2.2lb), Submerged Pump 1set, Pipe Clip 4pcs, Copper Connector 1pc
